- With variety of options can be provided for different purposes
- Tilting wheel head. It could be tilted easily and swiveled 360° on the horizontal plane. Both of these features make it easy to set the rake and relief angles and make for a wide angle or grinding
- Adopt precise roll guide on the table, it make the table is stable and operated smoothly.
Features
- With variety of options can be provided for different purposes.
- Simple to set up.
- Easy to operate.
- Grinding fast and high accuracy.
Specifications:
- Longitudinal travel of table: 230mm
- Cross travel of saddle: 180mm
- Vertical adjustment of wheel head: 120mm
- Rotary angle of wheel head: 360°
- Rotary angle of up-down spindle: 360°
- Working table area: 620 x 190mm
- Size of wheel:
- 180 x 25 x 31.75mm
- 125 x 50 x 31.75mm
- Speed of wheel: 3,600 RPM
- Motor: 3/4 HP, 110V / 220V / 380V
- N.W. / G.W.: 280kgs / 320kgs
- Size of packing (L x W x H): 1,000 x 850 x 1,540mm
